The As-Built Drawings Field Verification Checklist

Checklist

Introduction

In the architecture and construction industry, the success of a renovation project relies entirely on the accuracy of the existing conditions documentation. If an architect designs a multi-million dollar fit-out based on flawed As-Built drawings, the project is doomed before the first wall is framed.

While 3D laser scanning (Scan-to-BIM) has revolutionized data capture, many firms still rely on manual field verification for smaller projects or to supplement point cloud data. Missing a critical measurement while on-site means a costly, time-consuming return trip. In this guide, our senior VDC consultants provide the ultimate field verification checklist to ensure you capture every necessary detail the first time.

Key Takeaways

Problem Statement: The Danger of Assumption

When a junior architect is sent to a site with a laser disto and a clipboard, the most common mistake is assuming orthogonal geometry. They measure the length and width of a room, assume it is a perfect rectangle, and leave.

Back in the office, when they attempt to draw the overall floor plan, the rooms don’t fit together. The “rectangle” was actually a slight parallelogram, and because they didn’t measure the diagonals, they cannot resolve the geometry. This leads to “fudging” the CAD drawing, which eventually leads to custom casework not fitting during construction.

The Ultimate As-Built Field Verification Checklist

Print this checklist and clip it to your field board. Do not leave the job site until every item is checked off.

1. Pre-Site Preparation

• Legacy Documents: Obtain any existing blueprints, lease plans, or old CAD files from the building owner. (Use these only as a guide, never as truth).
• Equipment Check: Laser distance meter (Disto) with fresh batteries, 25’ tape measure (for short runs), flashlight, camera, graph paper, and colored pens.
• Access Confirmed: Ensure you have keys or clearance to access roof hatches, mechanical rooms, electrical closets, and basements.

2. General Spatial Geometry (The Bones)

• Overall Perimeters: Measure the longest possible unobstructed interior dimensions to establish the primary grid.
• Triangulation (Diagonals): In every major room, measure corner-to-corner diagonally. This is the only way to determine if a room is out of square.
• Wall Thicknesses: Measure at door jambs or window openings to determine the exact thickness of interior partitions and exterior envelopes.
• Level Changes: Document any steps, ramps, or sloping floors. Establish a benchmark “0’-0”“ elevation point.

3. Vertical Dimensions (The Z-Axis)

• Floor-to-Floor: If there is a stairwell, drop a tape measure down the shaft to get the exact floor-to-floor heights.
• Ceiling Heights: Measure to the underside of the finished ceiling (e.g., ACT grid or drywall).
• Structural Clearances: Pop a ceiling tile and measure to the underside of the structural deck and the lowest point of the structural beams.
• Window Heights: Measure the sill height (floor to bottom of window) and head height (floor to top of window) for every window type.

4. Doors, Windows, and Openings

• Door Widths: Measure the clear opening and the overall frame width.
• Door Swings: Note the direction of the swing (left-hand, right-hand) and whether it clashes with existing features.
• Window Locations: Measure from the nearest adjacent corner wall to the edge of the window frame, not the center (which is harder to draft).

5. MEP & Structural (Visible)

• Column Grid: Locate and dimension the structural columns. Determine if they are steel (I-beams) or concrete.
• Plumbing Walls: Identify wet walls by locating toilets, sinks, and floor drains. Measure the wall thickness (usually 6“ or 8“ for plumbing chases).
• Electrical Panels: Locate main electrical panels and communication boards. Ensure the required 36“ clearance is documented.
• HVAC: Note the location of massive duct runs, return air grilles, and any visible Roof Top Units (RTUs).

6. Photographic Documentation

• The 360 Spin: Stand in the center of every room and take overlapping photos covering all 360 degrees, plus the floor and ceiling.
• Detail Shots: Photograph complex pipe routing, structural connections, and any existing damage or water leaks.
• Context: Photograph the exterior context (sidewalks, adjacent buildings, parking).

Industry Challenges: The Shift to Scan-to-BIM

While this checklist is essential for manual measuring, the AEC industry is rapidly shifting away from tape measures entirely.

3D Laser Scanning (LiDAR) captures millions of data points per second, automatically documenting every diagonal, ceiling height, and MEP clash with millimeter precision. For projects over 5,000 square feet, sending a team to manually measure the space is no longer financially viable or sufficiently accurate. Firms are increasingly hiring surveyors to scan the building, and outsourcing the Point Cloud to specialized BIM firms to generate the As-Built Revit model.

ROI Analysis: The Cost of Missing Data

Scenario: An architect is tasked with designing an ADA-compliant restroom renovation in a 1920s building.

• The Mistake: The field technician measures the width of the room but forgets to locate the cast-iron waste stack buried in the corner.
• The Consequence: The architect designs the new ADA toilet layout. During demolition, the contractor discovers the waste stack exactly where the new toilet needs to go.
• The Cost: The architect must redesign the layout, submit a revision to the city, and delay construction by two weeks. Total cost of the missed dimension: $15,000+.

(Note: A laser scan would have captured the bump-out for the waste stack immediately).

Expert Insights

“When drawing your field sketches, exaggerate small dimensions so you can write the numbers legibly. If a door is 4 inches from a wall, draw it looking like it’s 2 feet away on your paper so you have room to write ‘4”’. You aren’t drawing to scale on site; you are collecting pure data.“ — Senior VDC Consultant, Core BIM Solutions

FAQs: As-Built Field Verification

Q: Should I use a laser disto or a tape measure? A: Both. Use a laser disto for long, overall runs across a room. Use a rigid 25-foot tape measure for short runs, wall thicknesses, and window sill heights where the laser might pass through the glass.

Q: Do you offer field measuring services? A: Core BIM Solutions specializes in the digital processing of field data. You capture the site (via hand measurements or hiring a local 3D laser scanner), send us the raw data/point cloud, and we generate the flawless CAD or Revit As-Built model.

Q: How accurate is a point cloud compared to hand measuring? A: A commercial terrestrial laser scanner is accurate to within 1-3 millimeters. A human with a tape measure is typically accurate to within 1-3 inches.

Conclusion

Creating accurate As-Built drawings is the foundation of any successful renovation project. While 3D laser scanning is the ultimate solution, rigorous manual field verification remains a necessary skill.

By aggressively adhering to this pre-flight checklist, you ensure that your team leaves the job site with 100% of the data required to draft a flawless, reliable set of existing condition CAD drawings.
