Nothing stalls a construction project faster than having your drawing set kicked back by the municipal permit office. When architectural CD sets are incomplete or unclear, the resulting rounds of municipal comments and revisions can push ground-breaking back by weeks or months.
Ensuring your drawings are permit-ready requires rigorous attention to detail and a standardized drafting workflow.
The High Cost of Incomplete CD Sets
Municipal reviewers are looking for strict compliance with local zoning and building codes (e.g., IBC). If a life-safety plan is missing, or if egress calculations are improperly documented, the reviewer will halt the process.
For architecture firms, constantly revising drawings to appease reviewers burns through the remaining design fee and frustrates the client.
The Permit-Ready Checklist
Whether drafting in-house or utilizing professional Construction Documentation Services, your final set must include these critical components:
1. General & Code Information
- Complete title block with project data and professional seals.
- Applicable code year and building classification.
- Occupancy loads and egress path calculations clearly diagrammed.
- Energy code compliance forms.
2. Site Plans
- Property lines, setbacks, and easements accurately depicted.
- Hardscape, parking calculations, and accessible routes.
- Stormwater management and grading concepts.
3. Architectural Plans
- Fully dimensioned floor plans with room names and areas.
- Reflected Ceiling Plans (RCP) showing lighting, diffusers, and bulkheads.
- Roof plans indicating slopes, drains, and mechanical equipment zones.
4. Elevations & Sections
- Exterior elevations showing material callouts and heights.
- Building sections detailing the structural assembly and floor-to-floor heights.
- Wall sections at a larger scale detailing insulation, vapor barriers, and structural connections.
5. Schedules & Details
- Comprehensive door, window, and finish schedules.
- ADA compliance details (restroom clearances, ramp slopes).
- Fire-rated assembly details (UL design numbers).
By standardizing this checklist and maintaining rigorous CAD or Revit templates, architecture firms can drastically reduce their permit review times and move their projects into the construction phase faster.
